Ceramic membrane cross flow filter is a functional, high-performance, and widely used filter. It can concentrate, clean and classify materials, and can operate continuously under high filtrate permeability; The material can be concentrated to a point where it is difficult to flow in just one cycle, and the filtrate is transparent and does not contain solid particles. Therefore, the filtered solid material can obtain a higher concentration.
It can be widely used in various industries, such as filtration of chemical products, clay, dyes, metal oxides and hydroxides, and industrial wastewater treatment. Low requirements for feed concentration, usually less than 10%, or even less than 0.1%; The filtration pressure is usually 0.4~0.6MPa; The solid concentration can reach over 80%, and the filtrate is very clear.
2. Basic Principles
Cross flow filtration is a high-speed circulating movement of the substance to be filtered through different pore size filter membrane channels through a circulating pump. Under the action of pressure, the filtrate is filtered out through a tangent line; The unfiltered liquid forms a turbulent effect due to high-speed circulation movement. Due to the high shear force of the fluid, it can timely wash away the deposited suspended particles and return them to the circulating material, avoiding blockage of the membrane tube channels.
